2-(2,4-二硝基苯甲基)吡啶(1151-97-9)紅外圖譜(IR1)
分子式:C12H9N3O4
分子量: 259.22
InChI:InChI=1S/C12H9N3O4/c16-14(17)11-5-4-9(12(8-11)15(18)19)7-10-3-1-2-6-13-10/h1-6,8H,7H2
InChIKey: KKFNJVINGIUTIH-UHFFFAOYSA-N
Smiles:C1(CC2=CC=C([N+]([O-])=O)C=C2[N+]([O-])=O)=NC=CC=C1
-
Mass
MS-NW-2501
2-(2,4-dinitrobenzyl)pyridine
C12H9N3O4 (Mass of molecular ion: 259)
Source Temperature: 150 °C
Sample Temperature: 100 °C
Direct, 75 eV
18.0 3.2
27.0 3.2
28.0 3.6
30.0 4.6
38.0 1.7
39.0 9.1
50.0 4.4
51.0 14.8
52.0 6.1
53.0 1.6
62.0 4.1
63.0 10.6
64.0 2.8
65.0 3.7
66.0 1.3
67.0 2.6
69.5 2.1
70.5 2.7
74.0 2.5
75.0 3.3
76.0 2.6
77.0 4.7
78.0 29.5
79.0 16.0
80.0 3.7
82.5 2.7
83.0 1.2
83.5 1.2
86.0 1.6
87.0 2.7
88.0 2.3
89.0 4.8
90.0 3.0
91.0 1.5
92.0 11.6
93.0 2.4
95.0 1.8
101.0 1.1
102.0 1.1
104.0 1.1
105.0 1.7
106.0 4.0
108.0 12.6
113.0 2.4
114.0 2.7
115.0 2.7
116.0 2.1
117.0 5.2
118.0 1.2
127.0 2.7
128.0 2.5
129.0 1.4
138.0 1.8
139.0 14.4
140.0 12.5
141.0 4.2
142.0 1.6
152.0 1.0
153.0 1.8
154.0 16.8
155.0 6.8
156.0 1.9
164.0 2.9
165.0 10.9
166.0 33.2
167.0 89.5
168.0 18.0
169.0 2.6
179.0 1.0
181.0 1.7
182.0 9.0
183.0 12.5
184.0 3.5
195.0 9.1
196.0 14.5
197.0 2.2
211.0 1.0
212.0 2.1
213.0 100.0
214.0 14.1
215.0 1.5
229.0 2.5
241.0 1.4
242.0 2.3
258.0 1.7
