CBZ-L-纈氨酸(1149-26-4)核磁圖(1HNMR)
分子式:C13H17NO4
分子量: 251.28
InChI:InChI=1S/C13H17NO4/c1-9(2)11(12(15)16)14-13(17)18-8-10-6-4-3-5-7-10/h3-7,9,11H,8H2,1-2H3,(H,14,17)(H,15,16)/t11-/m0/s1
InChIKey: CANZBRDGRHNSGZ-NSHDSACASA-N
Smiles:C(O)(=O)[C@H](C(C)C)NC(OCC1=CC=CC=C1)=O
-
Mass
MS-NW-2161
N-benzyloxycarbonyl-L-valine
C13H17NO4 (Mass of molecular ion: 251)
Source Temperature: 210 °C
Sample Temperature: 150 °C
Direct, 75 eV
15.0 1.2
18.0 3.8
26.0 1.8
27.0 16.6
28.0 26.3
29.0 4.6
30.0 2.1
31.0 1.5
37.0 1.7
38.0 2.9
39.0 14.3
40.0 2.0
41.0 24.5
42.0 3.4
43.0 37.8
44.0 6.8
50.0 5.7
51.0 11.9
52.0 3.9
53.0 3.1
54.0 2.2
55.0 3.1
56.0 12.5
57.0 1.0
62.0 1.5
63.0 3.8
64.0 1.2
65.0 9.1
70.0 2.1
71.0 1.3
72.0 3.8
73.0 11.6
74.0 4.0
75.0 1.3
77.0 26.7
78.0 6.1
79.0 56.9
80.0 5.8
83.0 8.1
89.0 5.0
90.0 6.6
91.0 90.6
92.0 9.0
98.0 2.7
101.0 91.1
102.0 3.4
105.0 2.7
106.0 1.0
107.0 50.1
108.0 100.0
109.0 7.7
116.0 4.2
148.0 1.0
162.0 11.3
163.0 1.4
206.0 2.9
251.0 6.9
